COMPUTER NUMERICAL CONTROL

Vertical Machining Centre

No. of Machines: 1

Model: BMV60TC24

Table Size: 1250*610*610

Travels: 1050*610*610

RPM: 6000

Distance from Table to Spindle Face: 140-750mm

Tool Change Time: 2.5sec

Machine Weight: 12000Kgs

Positioning Accuracy: +/-0.005mm

Repeatability Accuracy: +/-0.003mm

Maximum safe Load on Table: 1200 Kgs

Vertical Machining Centre

No. of Machines: 2

Model: BMV45TC20P

Table Size: 900*450*500

Travels: 600*450*500

RPM: 8000

Distance from Table to Spindle Face: 90-600mm

Tool Change Time: 2.5sec

Machine Weight: 8000Kgs

Positioning Accuracy: +/-0.005mm

Repeatability Accuracy: +/-0.003mm

Maximum safe Load on Table: 500 Kgs

CNC Lathe

Operated with Computer Numerical Control (CNC) systems and provided with precise design instructions, CNC Lathes are machine tools where the material or part is clamped and rotated by the main spindle, while the cutting tool that work on the material, is mounted and moved in various axis.

Vertical Machining Centre

Make: FEELER FFG

No. of Machines: 1

Table Size: 890x420

Travel: 760(X) , 420(Y) , 510(Z)

CNC - Turning Centre

No. of Machines: 2

Turning Diameter Max: 280mm(11")

Turning Length Max: 500mm(20”)

Chuck Diameter: 200mm(8”)

These Machines have machine tools where the material or part is clamped and rotated by the main spindle, while the cutting tool that work on the material, is mounted and moved in various axis.
